Description
|
MODEL+ PROCESSOR
|
SPECIFICATION
|
RAM+ SSD+ WIFI
|
PRICE
|
|
H48 J4125 DDR4
|
1.Intel Ce-leron J4125 Processor (4M Cache, 2.00 up to 2.7 GHz)
|
NO RAM +NO SSD+ NO WIFI
|
US$135.31
|
|
2. 4 Core 4 Thread
|
4G RAM+ 64G SSD+ WIFI
|
US$ 195.55
|
|
|
3. Intel UHD Graphics 600
|
8G RAM+ 128G SSD+ WIFI
|
US$ 230.62
|
|
Memory Type
|
Technology
|
DDR4-2133
|
|
Max Capacity
|
Up to 16GB
|
|
|
Socket
|
1* 284-pin SDSIMM
|
|
|
Display
|
VGA
|
Maximum support resolution 1920 x 1080p@24MHz
|
|
HD
|
Maximum support resolution 3200×2000@24Hz
|
|
|
Dual Display
|
Support Dual-Line Synchronous or Independent display
|
|
|
Ethernet
|
LAN
|
100/1000/2500 Mbps Intel i225,Support network wake up
|
|
WIFI
|
WIFI Module
|
300M, 802.11.b/g/n
|
|
Audio
|
Chipset
|
Apply Realtek ALC662Audio control chip, support for two channels, stereo，Line out
|
|
Expansion
|
Mini PCIe
|
1 x Half size Mini-PCIe
|
|
Storage
|
mSATA
|
1 x Full size mini PCIe slot
|
|
Other
|
Watchdog time
|
Supports (If you need this hardware, please let us know before payment)
|
|
Software
|
OS
|
pFsense/win-8/ win-10/ Linux/ ubuntu/ Centos etc.
|
|
Power Consumprtion
|
Power Type
|
DC-IN 5.5*2.5
|
|
Power Adapter
|
DC 12V5A/ 60W (AC TO DC, 100~240V)
|
|
|
TDP
|
11.5-28W
|
|
|
I/O
|
USB
|
2x USB3.0
|
|
VGA
|
1
|
|
|
HD
|
1
|
|
|
LAN
|
4
|
|
|
Physical Charateristics
|
Case Material
|
Aluminum Alloy
|
|
Installation
|
Wall/ Desktop
|
|
|
Dimensions
|
135x 126 x40mm
|
|
|
Weight
|
1.5KG
|
|
|
Enviroment
|
Operating Temperature
|
-10℃~65℃
|
|
Storage Temperature
|
15-35℃
|
|
|
operating humidity
|
5%-95% Relative humidity, no condensation
|
|
Shenzhen Helor Cloud Computer Co,.Ltd
The technical expertise of our highly knowledgeable and dedicated staff forms the backbone of our company. From the design stage to installation to our unsurpassed warranty, HLY clients are assured of the highest level of quality and service. |
||||||||
|
OEM & ODM Service
>>>Contact us<<< |
||||||||
|
ODM
|
1. PCBA desgin
2. Housing desgin 3. Software Customization: Booting image, UI, APP, Function… and so on |
|||||||
|
OEM
|
1. logo printing on housing
2. Customize package 3. Software Customization: Booting image, UI, APP, Function… and so on |
|||||||
